AB CLASS

Technical specifications

total Maximum power - 150W RMS @ 4 Ohms
maximum power per channel - 75W RMS @ 4 Ohms

inputs
inputs cha and chb - 02 P10

outputs
outputs cha and chb - 04 P10
send - 02 P10

protection - LED Overload / Short
clip - YES
fuse ampere - 2A
total consumption - 210W
source capacitance - 6000uF
frequency response - 10Hz to 30KHz
Input impedance - 10KW, 10Hz to 10kHz
vac power supply - 127/220
dimensions (mm) - (H) 485 x (L) 90 x (P) 370
weight (kg) - 5.61
